Williams

Gelato & Ice Cream

Display Cabinets

Stella

  • Tilt forward front glass with hydraulic system
  • Rear polycarbonate sliding doors with Italian make sliding system
  • Inclined display of Gelato/lce cream
  • AISI 304 matt finish stainless steel
  • Hot gas defrosting system
  • Pull-out refrigeration system
  • Electronic control panel with digital thermometer and thermostat
  • Italian make LED lightings
  • Gelato/lce Cream flavor display card with back-light
  • Power Supply-230V/1-Phase/50 Hz
  • Aluminium condensing water evaporating tray
  • Extra clear tempered glass
  • Twin compressor condensing unit for 18flv & 24flv Ice Cream cabinet
  • Side double vacuum glass, front & top-laminated glass

Technical Specifications

Model Lx:DxH(in mm) Refrigeration Capacity (in Ltrs) Product Tempº C Defrosting Climate Class
Nº/Cº/%RH
No.of Shelves No. of GN Pans GN Pans Size (in mm) Electrical Input
(Std) Watts
 ID-12flv 1200x1146x1350  Ventilated 631/60  -21/-18 GC 4/30/55 12 362x165x120 1996
 ID-18flv 1616x1146x1350 Ventilated 812/80 -21/-18 GC 4/30/55 18 362x165x120 2968
ID-24flv 2141x1146x1350 Ventilated 993/100 -21/-18  GC 4/30/55 24 362x165x120  3592
CS-4R 1239x1129x1365 Static -10/-15  – 4/30/55  1186



ID-Ice Cream Display, CS-Cold Stone, R-Refrigerated, GC-Hot Gas, GN-Gastronorm
